Autonics MX4W-A-FN Panel Meter
Autonics MX4W-A-FN AC/DC Current LCD Panel Meter (Indicator Only)
Ultra-compact 96×48 mm LCD panel meter for AC & DC current measurement without output.
Ideal for basic indication in compact OEM machines and electrical control panels.
The Autonics MX4W-A-FN is a compact LCD current panel meter designed for accurate AC and DC current indication without any control or communication output. With its ultra-short rear depth and wide power supply range, it is perfectly suited for space-constrained panels and OEM machinery where only local current display is required.
Key Features
Measures AC & DC current up to 5 A
Supports 4–20 mA current input
Clear 12-segment LCD display with large characters
Indicator-only model (no output)
Ultra-compact design with approx. 20 mm rear depth
Peak value monitoring and zero adjustment
Wide power supply: 24–240 VAC / VDC
IP54 front protection (panel mounted)
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | MX4W-A-FN |
| Input Type | AC/DC Current |
| Max Allowable Input | AC 5 A / DC 5 A |
| Display Range | −9999 to 9999 |
| Display Type | LCD, 12-segment |
| Character Height | Approx. 19 mm |
| Accuracy (23 ±5 °C) | ±0.1% F.S. (DC), ±0.3% F.S. (AC) |
| Output Type | None (Indicator only) |
| Power Supply | 24–240 VAC / VDC |
| Protection Rating | IP54 (front) |
| Operating Temperature | −10 to +50 °C |
Applications
OEM machinery panels
AC/DC current indication
Compact electrical enclosures
Power distribution panels
Test benches & R&D setups
Cost-sensitive automation panels
What’s in the Box?
Autonics MX4W-A-FN Panel Meter
Panel mounting brackets (2 pcs)
Terminal protection cover
Instruction manual
FAQ
Q1. Does MX4W-A-FN provide any output?
No. This is an indicator-only model with no control or communication output.
Q2. Can it measure both AC and DC current?
Yes, it supports both AC and DC current measurement.
Q3. Does it support 4–20 mA input signals?
Yes, standard 4–20 mA current input is supported.
Q4. Is it suitable for compact panels?
Yes, it has an ultra-short rear depth of around 20 mm.
Q5. What is the panel cut-out size?
Standard 92 × 45 mm panel cut-out.
