HM Digital PSC-154 EC/TDS/Temperature Controller

Product Summary:
The HM Digital PSC-154 is a precise EC/TDS/Temperature controller designed for continuous monitoring and control in water treatment, chemical processing, and industrial applications.

Key Features:

• EC Range: 0-9999 µS

• TDS Range: 0–5000 ppm

• Temperature Range: 1–75°C (33–167 °F)

• Digital calibration via push-button

• Bright 5/8″ LED display

• ATC: 1–65°C

• Adjustable set-point with relay control

• Output signal: 4–20mA (±1%)

• Alarm: Optional steady beep

• NPT probe with 3m cable

• AC 110V / 220V power

Application:

• Industrial water treatment systems

• Chemical dosing and mixing plants

• Cooling towers and boilers

• Aquaculture and hydroponics

• RO/DI water purification systems

Product Benefits:

• High accuracy (±2%) for critical monitoring

• Easy on-screen set-point control

• Integrates with pumps or solenoid valves

• Digital push-button calibration

• Compact and lightweight design

FAQs:

Q.1 What is the purpose of the relay control in the PSC-154?
The relay enables automatic control of external devices like pumps or valves when the EC/TDS exceeds the set limit.

Q.2 Can this controller be used in high-temperature water applications?
Yes, it supports temperature monitoring up to 75°C and includes Automatic Temperature Compensation (ATC).

Q.3 Is the calibration manual or automatic?
The PSC-154 features simple digital calibration using a push-button interface.
