MiBRX IO Cards – Miniature IO Cards for Selec PLC
Selec MiBRX IO Cards Series – Digital, Analog, Mixed & Special Function Expansion Modules
Modular IO expansion cards for Selec MiBRX PLCs are available in digital, analog, mixed-signal, load cell, datalogging, and WiFi variants for scalable automation systems.
The Selec MiBRX IO Cards Series is a comprehensive range of compact, pluggable expansion modules designed to increase the input/output capacity of MiBRX Series PLCs. Available in digital, analog, mixed IO, datalogging, load cell, and wireless communication variants, these modules offer flexible integration for industrial automation, machine control, and data acquisition systems.
Key Features
Compact, plug-in slot-type design for MiBRX PLCs
Available in Digital, Analog, Mixed IO, Load Cell, RTC, WiFi, and Datalogging variants
High-speed inputs/outputs up to 10 kHz
Options for isolated analog inputs (ISO models)
Relay and transistor output variants
Supports industrial protocols and accurate signal processing
CE & RoHS certified
Ideal for modular, scalable PLC systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Compatibility | Selec MiBRX Series PLCs |
| Types Available | Digital Input, Digital Output, Analog Input, Analog Output, RTD/TC, Load Cell, Datalogger, WiFi, Mixed IO |
| Digital IO Speed | Up to 10 kHz (model dependent) |
| Analog Input Types | Voltage, Current, RTD, Thermocouple |
| Analog Output | Voltage/Current (model dependent) |
| Load Cell Support | 24-bit resolution (LC card) |
| Isolation | Available on ISO variants |
| Mounting | Plug-in card for MiBRX PLC expansion slots |
| Certifications | CE, RoHS |
| Communication Options | WiFi card for wireless connectivity |
| Additional Features | RTC module, onboard logging, fast counters |
Applications
Industrial automation and machine control
PLC-based control panels
HVAC & Building management
Manufacturing and process automation
Data acquisition and monitoring systems
IoT-enabled smart factory solutions
What’s in the Box?
MiBRX IO Expansion Card (selected variant)
User leaflet/quick setup guide
Protective packing
FAQ
Q1. Are MiBRX IO Cards compatible with all Selec PLCs?
A1. No, they are specifically designed for the Selec MiBRX Series PLC family.
Q2. Can multiple IO cards be used at once?
A2. Yes, you can insert multiple cards into the available slots of the MiBRX base unit.
Q3. Do analog IO cards offer isolation?
A3. Certain variants, such as AI02-V-ISO, AI02-I-ISO, and AI02-RTD-ISO, provide galvanic isolation.
Q4. What is the maximum IO frequency supported?
A4. Some digital IO variants support up to 10 kHz fast inputs/outputs.
Q5. Are these cards plug-and-play?
A5. Yes, the design supports quick installation without rewiring or external modules.
