R-Tek Digital Depth & Thickness Gauges

A. Product Overview

R Tek Digital Depth and Thickness Gauges provide convenient digital measurement for applications where dimensional accuracy is important.

RK 521 Digital Depth Gauge
The RK 521 is designed for depth measurement of holes, grooves, slots, recesses and similar features. It offers a digital display for easy reading and supports measurement in millimetres and inches.

RK 522 Digital Thickness Gauge
The RK 522 is designed for measuring the thickness of suitable materials such as paper, plastic, leather, films and other thin materials. Its digital display allows users to check thickness quickly during inspection and quality control.

Both models are suitable for routine industrial measurement, production checking and laboratory use.

B. Working Principle

R Tek Digital Depth and Thickness Gauges work by converting mechanical movement into a digital measurement value.

In the RK 521 Digital Depth Gauge, the measuring rod or contact point moves according to the depth of the hole, slot or recess being checked. The internal electronic measuring system converts this displacement into a digital reading shown on the LCD display.

In the RK 522 Digital Thickness Gauge, the material is placed between the measuring contact surfaces. The movement caused by the material thickness is detected by the internal measuring mechanism and converted into a digital value.

Digital indication helps reduce reading errors that can occur with conventional analogue scales.

C. Why It Is Used

R Tek Digital Depth and Thickness Gauges are used when precise and repeatable dimensional measurement is required.

Common applications include:

• Measuring hole depth
• Measuring slot depth
• Measuring recess depth
• Checking machined components
• Measuring paper thickness
• Measuring plastic thickness
• Measuring film thickness
• Measuring leather thickness
• Product inspection
• Quality control
• Production line checking
• Laboratory measurement
• Engineering inspection
• Workshop measurement

These instruments help users verify whether a component or material is within the required dimensional specification.

D. Suitable Buyers

R Tek Digital Depth and Thickness Gauges are suitable for:

• Machine shops
• Manufacturing companies
• Quality control departments
• Inspection departments
• Engineering workshops
• Tool rooms
• Automobile component manufacturers
• Plastic manufacturers
• Packaging companies
• Paper industries
• Leather industries
• Film manufacturers
• Research laboratories
• Educational laboratories
• Maintenance departments
• Industrial testing facilities
• Instrument dealers and distributors

Frequently Asked Questions

1. What are R Tek Digital Depth and Thickness Gauges?
They are digital measuring instruments used for dimensional measurement of depth and material thickness.

2. Which models are available in this range?
The range includes RK 521 Digital Depth Gauge and RK 522 Digital Thickness Gauge.

3. What is the RK 521 used for?
The RK 521 is used for measuring the depth of holes, slots, grooves, recesses and similar mechanical features.

4. What is the measuring range of the RK 521?
The RK 521 has a measuring range of 0 to 25.4 mm or 0 to 1 inch.

5. What is the RK 522 used for?
The RK 522 is designed for measuring the thickness of suitable materials such as paper, plastic, leather and films.

6. What is the measuring range of the RK 522?
The RK 522 has a measuring range of 0 to 12.7 mm or 0 to 0.5 inch.

7. Can the RK 521 measure hole depth?
Yes. It is suitable for measuring the depth of holes and similar recessed features.

8. Can the RK 521 be used for machining inspection?
Yes. It can be used for checking machined components during production and quality inspection.

9. Can the RK 522 measure plastic thickness?
Yes. The RK 522 can be used for suitable plastic sheets and similar materials within its measuring range.

10. Can the RK 522 measure paper and film thickness?
Yes. It is suitable for measuring materials such as paper and films, provided the material is compatible with the gauge and within its measuring range.

11. Do these gauges provide digital readings?
Yes. Both models provide digital indication, making measurements easier to read compared with conventional mechanical scales.

12. Can measurements be taken in millimetres and inches?
The RK 521 supports millimetre and inch measurement. Model specific unit functionality should be confirmed from the product specification before purchase.

13. Are these gauges suitable for quality control applications?
Yes. They are suitable for dimensional inspection and routine quality control in manufacturing and laboratory environments.

14. What is the difference between RK 521 and RK 522?
The RK 521 is designed for depth measurement, while the RK 522 is designed for thickness measurement.

15. How should I select between RK 521 and RK 522?
Choose the RK 521 when you need to measure holes, slots or recesses. Choose the RK 522 when you need to measure the thickness of materials such as paper, plastic, leather or film.
