Selec MV35-1-G-40/300V-CE Digital Voltmeter
Customize
Share :
The Selec MV35-1-G-40/300V-CE is a high-accuracy digital voltmeter designed for industrial and commercial electrical panels. With a 96×96 mm form factor, it measures AC voltage in the 40–300 V range and is CE-certified for safety and reliability.
Key Features
Measurement range: 40–300V AC
96×96 mm front fascia for standard panel cutouts
CE-certified design
High-clarity 3-digit LED display
True RMS AC voltage measurement
Long-life internal circuitry, stable performance
Rear terminal connections for quick mounting
Wide operating temperature range
Ideal for LT panels, MCC panels, AMF panels, and control boxes
Technical Specifications (Table)
| Parameter | Specification |
|---|---|
| Model | MV35-1-G-40/300V-CE |
| Brand | Selec |
| Measurement Type | AC Voltage |
| Voltage Range | 40–300V AC |
| Display Type | LED, 3-digit |
| Form Factor | 96×96 mm panel meter |
| Operating Temperature | -10°C to +55°C |
| Accuracy | ±1% of reading |
| Frequency Range | 45–65 Hz |
| Power Supply | Self-powered / auxiliary (depending on variant) |
| Terminal Type | Rear screw terminals |
| Certification | CE |
| Protection | Front IP54 (panel mounted) |
| Mounting | Panel flush mounting |
| Cut-Out Size | 92×92 mm |
Applications
Control panels
Motor control centers (MCC)
AMF/ATS panels
Distribution boards
Industrial automation panels
Remote monitoring panels
Utility metering panels
What’s in the Box
Selec MV35-1-G-40/300V-CE Voltmeter
Panel mounting clips
Instruction manual
Warranty card (1 year)
FAQ
1. What voltage range does this model measure?
It measures 40–300V AC in single-phase systems.
2. Can it be used in industrial LT panels?
Yes, it is designed for MCC, PCC, DG panels, and control boxes.
3. Does it support True RMS?
Yes, the voltmeter provides accurate RMS readings across varying loads.
4. Is this CE certified?
Yes, the model is fully CE-approved.
5. What is the panel cut-out size?
Standard 92×92 mm cut-out.
6. What is the display type?
A bright LED 3-digit display visible in indoor industrial environments.
