HTC FG-2010 Function Generator
High-precision 10MHz Function Generator with multiple waveform output and built-in frequency counter.
Product Summary:
HTC FG-2010 is a versatile 10MHz Function Generator designed for waveform testing, frequency analysis, and general-purpose lab use.
Key Features:
Wide frequency range: 0.1Hz to 10MHz
Outputs sine, square, triangle, pulse, and sawtooth waveforms
TTL/CMOS compatible output
Built-in frequency counter (1Hz to 20MHz)
Low distortion (<1% from 10Hz to 100kHz)
Adjustable DC bias and symmetry
Fast rise time (<35ns) for square waves
Multiple attenuation levels: 20dB, 40dB
Frequency meter with high accuracy: ≤0.003%±1 digit
Compact design: 310 x 230 x 90 mm
Applications:
R&D and electronic design labs
Audio signal testing
Educational training equipment
Communication and broadcasting systems
Troubleshooting analog circuits
Product Benefits:
High waveform accuracy and stability
Multiple waveform generation in a single device
Integrated frequency counter reduces need for separate instruments
Ideal for both educational and professional electronic environments
Simple interface for ease of use
FAQs:
Q1: What is the maximum frequency range of the FG-2010?
A1: The FG-2010 supports frequency output from 0.1Hz up to 10MHz.
Q2: Can it generate both analog and digital waveforms?
A2: Yes, it provides analog waveforms (sine, triangle, sawtooth) and digital-compatible outputs (TTL/CMOS).
Q3: Does the FG-2010 come with any accessories?
A3: Yes, it includes a power cord, BNC line cable, and user manual.
