HTC Instruments DC 3005-II DC 5A Linear Dual Power Supply

Product Summary:
The HTC DC 3005-II is a high-precision dual-channel linear DC power supply offering up to 5A output, ideal for R&D, lab, and industrial testing.

Key Features:

• Dual-channel regulated output with up to 5A

• Line Regulation: CV ≤0.01% + 3mV ; CC ≤0.2% + 3mA

• Load Regulation: CV ≤0.01% + 3mV ; CC ≤0.2% + 3mA

• Ripple and Noise: CV ≤1mV rms ; CC ≤3mA rms

• Constant current & short-circuit protection

• Accurate digital voltage and current indication

• Input Voltage: 220VAC ±10%, 50Hz ±2%

• Accessories included: Power Cord, Manual, Test Leads

• Compact size: 240(H) x 150(W) x 270(D) mm

Applications:

• Electronics research and development

• Lab testing and calibration

• Educational institutions and technical training

• Embedded system development and prototyping

Product Benefits:

• Reliable power output for sensitive electronics

• Built-in protection prevents circuit damage

• High accuracy for precise testing and development

• User-friendly operation with digital display

FAQs:

Q1: What is the maximum output current of the DC 3005-II?
A: The maximum output current is 5A per channel.

Q2: Is this power supply suitable for short-circuit testing?
A: Yes, it features constant current and short-circuit protection.

Q3: Does the device support dual independent voltage outputs?
A: Yes, the unit provides dual regulated outputs for simultaneous usage.
