MECO DIT 99E Digital Insulation Tester

Product Summary:
The Meco DIT-99E Digital Insulation Tester is a compact, portable, and reliable device designed for insulation resistance testing of motors, transformers, and electrical systems using a 500V DC test voltage.

Key Features:

• 3½ Digit LCD Display with 1999 Count

• High Accuracy: ± (3% rdg + 2 dgt)

• Single-person push button operation

• Meets IS 10656-1983 and IEC 61010 standards

• Insulation resistance up to 200 MΩ

• Terminal voltage >85% of rated voltage

• Compact, lightweight & portable

• Includes carrying case and manual

Applications:

• Insulation resistance testing in motors and transformers

• Testing electrical and communication cables

• Industrial, commercial, and residential installations

• Testing household appliances like mixers and washing machines

Product Benefits:

• Ensures electrical safety by checking insulation quality

• Portable design makes it ideal for field testing

• Conforms to industry safety standards

• Reliable readings with high accuracy

• User-friendly with single-button operation

FAQ:

Q1. What is the insulation resistance range of the Meco DIT-99E?
A: It can measure insulation resistance from 0 to 200 MΩ using a 500V DC test voltage.

Q2. Is the DIT-99E suitable for household appliance testing?
A: Yes, it is ideal for testing insulation in appliances like washing machines, mixers, and toasters.

Q3. What power source does it require?
A: It operates on 6 x 1.5V AA batteries (9V total).
