MECO MC 904 Analog Insulation Tester

Product Summary:
The MECO MC 904 is a robust and precise analog insulation tester designed for measuring insulation resistance up to 500MΩ at 500V. It meets IEC 61010 standards and is ideal for electrical professionals and industries.

Key Features:

• 500V insulation resistance measurement up to 500MΩ

• High accuracy: ±5% of indicated value (effective range)

• Long 80 mm scale for easy reading

• Push-button operation for single-person use

• Terminal voltage > 85% of rated voltage

• Durable ABS yellow case with polycarbonate front cover

• IEC 61010 compliance (CAT II, 1000V phase-earth)

• IS 10656-1983 compliant design

Applications:

• Electrical equipment testing (motors, transformers, machines)

• Communication network cable insulation checks

• Industrial, commercial, and residential electrical installations

• Power distribution cable testing

• Household appliance testing (mixers, toasters, washing machines)

Product Benefits:

• Reliable analog measurement for insulation resistance

• Enhanced durability for rugged field use

• Compliant with global electrical safety standards

• Easy operation with push-button control

• Wide measurement range suitable for diverse applications

FAQs:

Q1. What is the maximum insulation resistance range of the MECO MC 904?
A: It can measure insulation resistance up to 500 megaohms at 500V.

Q2. Is the MECO MC 904 suitable for home appliances testing?
A: Yes, it is ideal for testing insulation resistance in household appliances like mixers, washing machines, and toasters.

Q3. What standards does the MC 904 comply with?
A: It complies with IEC 61010 (CAT II) and is designed to conform to IS 10656-1983.
