Overview

RL-200W-EXC is a Class-I chassis-type switching power supply designed for high-power industrial and OEM applications. It supports a wide AC input voltage range of 85–264 VAC (selectable ranges) and delivers stable, high-efficiency DC output across multiple voltage options.

The power supply complies with EMC EN55035 / EN55032 Class-A standards and is engineered for continuous operation in demanding industrial environments.

Key Features

• Class I structure

• Wide input voltage range: 85–264 VAC, 50/60 Hz (switch selectable)

• Withstands VAC surge input for 5 seconds

• EMC compliant: EN55035 / EN55032 Class A

• Operating temperature up to 70°C

• Over-voltage category III

• Low standby power consumption (<0.2W)

• Built-in protections: OVP, OLP, SCP

• 3-year manufacturing warranty

Available Variants

• 12V DC – 16.67 A

• 15V DC – 13.34A

• 24V DC – 8.34A

• 36V DC – 5.56A

• 48V DC – 4.17A

All variants share the same electrical, safety, and mechanical design, differing only in output voltage and current rating.

Applications

• Industrial control systems

• Industrial equipment & OEM machinery

• Power systems

• Rail transportation equipment

• Industrial & commercial lighting systems

Why Choose This SMPS?

RL-200W-EXC offers high power density, wide input flexibility, robust protection features, and proven industrial reliability, making it an ideal 200W power supply for OEMs, panel builders, and automation engineers.

FAQs

Q1. What is the input voltage range of the RL-200W-EXC SMPS?
It supports 85–132 VAC and 180–264 VAC (AC selectable) and 140–370 VDC, making it suitable for varied industrial power conditions.

Q2. What output voltage options are available?
The RL-200W-EXC is available in 12V, 15V, 24V, 36V, and 48V DC variants.

Q3. Does the output current vary with voltage selection?
Yes. Output current varies according to the selected output voltage while maintaining a total power rating of 200W.

Q4. Is this SMPS suitable for automation control panels and OEM machines?
Yes. It is designed specifically for industrial automation panels, OEM equipment, and control systems.

Q5. What protection features are included?
The SMPS includes overload, short-circuit, and over-voltage protection with automatic recovery (hiccup mode).

Q6. Can it operate at high ambient temperatures?
Yes. It can operate up to 70°C. Above 50°C, output power is derated as per the derating curve.

Q7. Does the RL-200W-EXC comply with safety and EMC standards?
Yes. It complies with UL62368-1, EN62368-1, and EN55032 / EN55035 Class A standards.

Q8. What is the warranty period?
The RL-200W-EXC comes with a 3-year manufacturing warranty.
