Overview

The RL-200W-EXL is a high-reliability 200W chassis-type switching power supply designed for industrial environments where stable DC power, high efficiency, and long service life are essential. It supports a wide AC input range of 85–264 VAC, ensuring consistent performance even under unstable mains conditions.

With Class I construction, high operating temperature capability up to 70°C, and compliance with EN 55035 / EN 55032 Class A EMC standards, this SMPS is well suited for demanding automation and power system applications.

Key Features

• Rated output power: 200W

• Wide input voltage range: 85–264 VAC, 50/60 Hz

• Withstands VAC surge input for 5 seconds

• Maximum operating temperature: 70°C

• Low no-load power consumption ≤ 0.5W

• EMC compliant: EN 55035 / EN 55032 Class A

• Protection: Overload, Overvoltage, Short-Circuit

• Overvoltage Category III

• Compact chassis-mount design

• 3-year manufacturing warranty

Available Variants

The RL-200W-EXL series is available in the following DC output options:

• 12V DC – 16.67 A

• 15V DC – 13.34A

• 24V DC – 8.34A

• 36V DC – 5.56A

• 48V DC – 4.17A

All variants share identical electrical, thermal, and safety characteristics, differing only in output voltage and current rating.

Applications

• Industrial automation & PLC panels

• Control and instrumentation panels

• OEM industrial machinery

• Power distribution systems

• Rail transit electronics

• Industrial and architectural lighting

Why Choose This SMPS?

The RL-200W-EXL offers an optimal combination of power density, efficiency, and protection, making it a dependable choice for OEMs, panel builders, and automation engineers. Its wide input tolerance, strong EMC compliance, and reliable protection mechanisms ensure long-term, trouble-free operation in industrial installations.

FAQs

Q1. What is the input voltage range of RL-200W-EXL?
It supports a wide input range of 85–264 VAC at 50/60 Hz.

Q2. Which DC output voltages are available?
12V, 15V, 24V, 36V, and 48V DC options are available.

Q3. Is this SMPS suitable for automation panels?
Yes, it is designed specifically for industrial automation and control panels.

Q4. What protection features are included?
Overload, overvoltage, and short-circuit protection with automatic recovery.

Q5. Can it operate in high-temperature environments?
Yes, it supports ambient temperatures up to 70°C.

Q6. Is the power supply EMC compliant?
Yes, it complies with EN 55035 / EN 55032 Class A standards.

Q7. What is the no-load power consumption?
No-load power consumption is ≤ 0.5 W.

Q8. What warranty is provided?
A 3-year manufacturing warranty is included.
