Overview

RL-450W-EXC is a high-power, Class-I chassis-type switching power supply designed for demanding industrial and OEM environments. It supports switch-selectable wide AC input ranges and delivers stable DC output with high efficiency and robust protection features.

The unit complies with EMC EN55035 / EN55032 Class-A standards and is suitable for continuous operation in industrial control panels, power systems, and automation equipment.

Key Features

• Class I structure

• Wide input voltage range: 85–264 VAC, 50/60 Hz (switch selectable)

• Withstands VAC surge input for 5 seconds

• EMC compliant: EN55035 / EN55032 Class A

• Operating temperature up to 70°C

• Over-voltage category III

• Low standby power consumption (<0.2W)

• Built-in protections: OVP, OLP, SCP

• 3-year manufacturing warranty

Available Variants

• 12V DC – 37.5A

• 15V DC – 30.0A

• 24V DC – 18.75 A

• 36V DC – 12.5A

• 48V DC – 9.38A

All variants share the same electrical, safety, and mechanical design, differing only in output voltage and output current rating.

Applications

• Industrial control systems

• Industrial equipment & OEM machinery

• Power systems

• Rail transportation equipment

• Industrial & commercial lighting systems

Why Choose This SMPS?

RL-450W-EXC provides high power density, strong overload handling, wide input flexibility, and industrial-grade reliability. It is ideal for panel builders and OEMs requiring a dependable 450W chassis power supply for automation and power-hungry applications.

FAQs

Q1. What input voltage range does the RL-450W-EXC support?
It supports 85–132 VAC and 180–264 VAC (switch selectable) and 140–370 VDC, making it suitable for varied industrial power conditions.

Q2. What DC output voltages are available?
The RL-450W-EXC series is available in 12V, 15V, 24V, 36V, and 48V DC variants.

Q3. Does output current vary with voltage selection?
Yes. Output current changes according to the selected output voltage while maintaining a total power rating of 450W.

Q4. Is this SMPS suitable for heavy-load automation panels?
Yes. It is designed for high-power industrial automation panels, OEM machines, and control cabinets.

Q5. What protection features are included?
The power supply includes overload, short-circuit, and over-voltage protection with hiccup auto-recovery.

Q6. Can it operate in high ambient temperatures?
Yes. It can operate up to 70°C. Output power derating applies beyond standard ambient limits as per design.

Q7. What EMC standard does this model meet?
It complies with EN55035 / EN55032 Class A conducted and radiated emission requirements.

Q8. What is the warranty period?
The RL-450W-EXC comes with a 3-year manufacturing warranty.
