Overview

RL-600W-EXC is a Class-I, high-capacity chassis-type switching power supply engineered for demanding industrial and OEM environments. It supports switch-selectable wide AC input ranges and delivers stable, high-efficiency DC output suitable for continuous operation.

The power supply complies with EMC EN55035 / EN55032 Class-A standards and is ideal for power-intensive automation systems, industrial machinery, and control cabinets.

Key Features

• Class I structure

• Wide input voltage range: 85–264 VAC, 50/60 Hz (switch selectable)

• Withstands VAC surge input for 5 seconds

• EMC compliant: EN55035 / EN55032 Class A

• Operating temperature up to 70°C

• Over-voltage category III

• Low standby power consumption (<0.2W)

• Built-in protections: OVP, OLP, SCP

• 3-year manufacturing warranty

Available Variants

• 12V DC – 50A

• 15V DC – 40A

• 24V DC – 25A

• 36V DC – 16.67 A

• 48V DC – 12.5A

All variants share the same electrical, safety, and mechanical design, differing only in output voltage and current rating.

Applications

• Industrial control systems

• Industrial equipment & OEM machinery

• Power systems

• Rail transportation equipment

• Industrial and commercial lighting systems

Why Choose This SMPS?

RL-600W-EXC offers high power density, excellent efficiency, wide input flexibility, and robust protection features. It is ideal for panel builders and OEMs requiring a reliable 600W chassis power supply for high-load automation and industrial applications.

FAQs

Q1. What input voltage range does the RL-600W-EXC support?
It supports 85–132 VAC and 180–264 VAC (switch selectable) and 140–370 VDC, suitable for varied industrial power sources.

Q2. What output voltage options are available?
The RL-600W-EXC series is available in 12V, 15V, 24V, 36V, and 48V DC variants.

Q3. Does output current change with voltage selection?
Yes. Output current varies according to the selected output voltage while maintaining a total power rating of 600W.

Q4. Is this SMPS suitable for high-power automation panels?
Yes. It is designed for heavy-duty automation panels, OEM machinery, and industrial control cabinets.

Q5. What protection features are included?
The unit includes overload, short-circuit, and over-voltage protection with hiccup auto-recovery.

Q6. Can it operate in high ambient temperatures?
Yes. It can operate up to 70°C ambient temperature. Output power derating applies as per design.

Q7. What EMC standard does this model meet?
It complies with EN55035 / EN55032 Class A conducted and radiated emission requirements.

Q8. What warranty is provided?
The RL-600W-EXC comes with a 3-year manufacturing warranty.
