UNI 101 ZDA 48 25 00 AL5

UNI 101 ZDA 48 25 00 AL5

Write a review
₹240.00 ₹285.00
Add Note
Quantity
Buy Now
Product Details
  • Product Name: UNI 101 ZDA 48 25 00 AL5
  • Manufacturer: Unison Controls
  • Input Control Voltage: 4-32V DC
  • Input Current: 4-16mA
  • Input Indication: Green LED
  • Load Voltage Range: 24-480V AC (47-63 Hz)
  • Load Current: 25 Amps
  • Peak Inverse Voltage (PIV): 800V
  • I²T Rating: 340A²S for 9.6ms
  • Switching Type: Zero Cross Over Switching
  • Body Insulation: 6kV for 1 minute
  • Input to Output Isolation: 6kV for 1 minute
  • Surge Voltage Protection: 2700Vrms
  • Design: Compact 45mm Panel Mounting
