BK-BWPK-P Autonics Area Sensor
Non-returnable
₹20,973.00
Product Details
| Product | Description |
|---|---|
| Brand | Autonics |
| Model no | BK-BWPK-P |
| Sensing type | Through-beam |
| Sensing distance | 0.1 to 3m |
| Light source | Infrared LED(850nm modulated) |
| Optical axis pitch | 25mm |
| Number of optical axes | 5 |
| Sensing height/Total length | 100mm |
| Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
| Operation mode | Selectable Light ON/Dark ON by switch |
| Environment Ambient illumination | Ambient light: max. 10,0001x, Incandescent lamp: max. 3,0001x (received light side illumination) |
| Environment Ambient temperature | -10 to 55°C, storage: -20 to 60°C |
| Protection structure | IP40 |
| Approval | CE |
| Environment Ambient humidity | 35 to 85% RH, storage: 35 to 85%RH |
| Response time | Max. 30ms |
| Material | Case: Polycarbonate/Acrylonitrile butadiene styrene, Sensing part: Polymethyl methacrylate |
| Cable specification | 04.0mm, 4-wire. 2m (emitter: 04.0mm, 3-wire, 2m) (AWG 22, core diameter: 0.08mm, number of cores: 60, insulator out diameter 01.25mm) |
| Weight | Approx. 220g(approx. 180g) |
