GLDA01D-F034 Honeywell Limit Switch

Product Description

Brand:

• Honeywell

Model:

• GLDA01D-F034

Actuators:

• Side rotary
• Top pin plunger
• Top roller plunger
• Top roller lever
• Top wobble actuator

Termination Options:

• 0.5-14 NPT
• PG 13.5
• 20 mm
• PF 1/2
• Deutsch style 4-pin connector
• Other cable/connector options available (contact Honeywell Representative)

Contact Options*:

• GLC (metal housing) / GLD (plastic housing):
  • 1NC/1NO
  • 2NC
  • 2NO
• GLE (metal housing):
  • 1NC/1NO
  • 2NC
  • 2NO
  • 2NC/2NO

Contact Type:

• Snap-action
• Slow-action (break-before-make - BBM)
• Slow-action (make-before-break - MBB)

Contact Material:

• Silver (standard)
• Gold-plated (for low-energy applications)

Electrical Ratings:

• Thermal current (Ith): 10 A
• Rated insulation voltage (Ui): 300 V
• Rated impulse voltage: 2.5 kV

Sealing:

• NEMA 1, 4, 12, 13
• IP66

Operating Conditions:

• Temperature Range: -40 °C to 85 °C [-40 °F to 185 °F]
• Mechanical Life: Up to 10 million cycles
• Max. Actuation Frequency:
  • 250 operations/minute
  • 100 operations/minute (for wobble actuators)

Environmental Ratings:

• Pollution Code: 3
• Shock Resistance:
  • 50 g (per IEC 60068-2-27)
  • Railway application per IEC 61373 Class I Car B Type
• Vibration Resistance:
  • 10 g (per IEC 60068-2-6)
  • Railway application per IEC 61373 Class I Car B Type

Approvals:

• CE
• UKCA
• UL
• CSA
• CCC1

Conformance to Standards:

• EN50047
• IEC/EN 60947-5-1
• CSA C22.2 #14
• UL 508
• CCC1 GB14048.5
• EN45545-2 (for GLC/GLE models)
