PSC-154
Non-returnable
₹22,680.00
Product Details
The HM Digital PSC-154 is a robust and reliable controller designed to maintain TDS/EC levels in high-output commercial systems. With advanced features like extended range, digital calibration, on-screen temperature display, tri-color indicators, and 4-20mA output, it ensures precise monitoring and control.
The built-in sensor with Automatic Temperature Compensation (ATC) guarantees accurate readings across varying temperatures. The bright 5/8″ LED display provides clear and easy-to-read measurements.
Key Features
- Large, Bright LED Display: Clear visibility of TDS/EC and temperature readings.
- 4-20mA Output: Seamless integration with PLCs for data logging.
- Adjustable Alarm: Alerts when TDS/EC levels exceed the user-set threshold.
- Device Control: Operates pumps, solenoid valves, or other devices via relay control.
- On-Screen Temperature Display: Shows readings in both Celsius (°C) and Fahrenheit (°F).
- Digital Calibration: Easy push-button calibration.
- Single Point Set-Point: Adjust settings using simple on-screen up/down buttons.
- Automatic Temperature Compensation (ATC): Maintains accuracy across temperature fluctuations.
- Includes Probe: Comes with the SP-1-PSC sensor probe for reliable operation.
Product Specifications
| Parameter | Specification |
|---|---|
| EC Range | 0 – 9999 µS |
| TDS Range | 0 – 5000 ppm |
| Temperature Range | 1 – 75°C (33 – 167°F) |
| Accuracy | ±2% of the reading |
| Conversion Factor | NaCl (avg. 0.5) |
| Resolution | 0.1 µS/ppm (0-999); 1 µS/ppm (1000-9999) |
| Calibration | Digital via push button |
| Relay Voltage | 5V |
| Output Signal | 4-20mA |
| Output Accuracy | ±1% |
| Display | Bright 5/8″ LED |
| Probe | 1/2″ bushing (NPT), 3 meters (9.8 ft) shielded cable |
| Power Source | AC 110V / AC 220V |
| Dimensions | 7.2 x 7.2 x 11.1 cm (2.8 x 2.8 x 4.4 in.) |
| Weight (Monitor) | 241 g (8.5 oz) |
| Total Weight (Shipping) | 610 g (1 lb 5.5 oz) |
Additional Features
- Alarm System: User-optional steady beep for alerting high TDS/EC levels.
- Relay Control: The dry contacts in the relay can control external devices like pumps and solenoid valves.
- Temperature Compensation: Ensures readings remain consistent across 1 – 65°C.
Warranty
The PSC-154 comes with a one-year warranty, ensuring peace of mind and reliable performance.
Ideal for commercial applications, the HM Digital PSC-154 delivers precision and dependability in managing TDS/EC levels.
