UNI-T MSO2104X Mixed Signal Oscilloscope
The MSO2000X series mixed-signal oscilloscope offers exceptional performance and versatile features, making it a powerful tool for advanced signal analysis. Key specifications include:
- Bandwidth: 100 MHz
- Analog Channels: 4
- Real-Time Sample Rate: 5 GSa/s
- Maximum Memory Depth: 100 Mpts per channel
- Waveform Capture Rate: Up to 2,000,000 waveforms per second
- Digital Channels: 16
The oscilloscope is equipped with exclusive Ultra Phosphor 3.0 technology, delivering a high waveform capture rate and a 256-level brightness color temperature display for detailed waveform visualization. It also features an advanced digital trigger system, offering trigger accuracy down to 10 ps.
In addition, the device supports 9 types of advanced triggers and 9 types of serial bus triggering and decoding, providing flexibility for various applications. The oscilloscope is capable of performing advanced functions and analysis, such as spectrum analysis, power analysis, histograms, waveform recording, enhanced resolution, pass/fail testing, and search and navigation.
A 10.1-inch capacitive touchscreen allows for intuitive operation, with support for various gestures to manage waveforms. Remote control is possible through its WebServer feature, adding convenience for remote monitoring and operation.
The warranty for the MSO2000X series is provided as per the brand's policy.
