BZE6-2RN8 Honeywell Limit Switch

Product Summary:
The Honeywell BZE6-2RN8 is a rugged, industrial-grade limit switch designed for demanding environments. It features a roller lever actuator, electrostatic epoxy-coated zinc housing, and versatile SPDT or DPDT snap-action contacts.

Key Features:

• Roller lever actuator for mechanical operation

• Electrostatic epoxy-coated zinc die-cast housing

• Sealing: NEMA 1, 3, 4, IP66 with boot; NEMA 1, IP40 without boot

• Switching options: SPDT, SPDT-DB, DPDT

• Mechanical endurance up to 5 million cycles

• Electrical life up to 50,000 cycles at full load

• Operating temperature range: -40°C to +71°C (with optional low-temp version)

• Snap-action contacts: 1NO/1NC or 2NO/2NC

• Agency approvals: UL, CSA, CE

Applications:

• Industrial machinery and OEM applications

• Conveyor and material handling systems

• Automated assembly lines

• Door interlocks and position feedback

• Robotics and packaging lines

Product Benefits:

• Long mechanical and electrical life for reduced downtime

• Rugged housing ensures durability in harsh conditions

• High sealing rating offers protection from dust and water

• Wide operating temperature range for various industries

• Multiple actuator and contact options for flexible integration

FAQs:
Q1: What type of actuator does the BZE6-2RN8 switch use?
A1: It uses a roller lever actuator suitable for detecting linear or rotary mechanical movements.

Q2: Is this switch suitable for outdoor or dusty environments?
A2: Yes, the switch with a boot seal provides NEMA 3 & 4 and IP66 protection, making it ideal for outdoor and dusty industrial applications.

Q3: Can the BZE6-2RN8 handle both AC and DC loads?
A3: Yes, it can be configured to switch both AC and DC loads, depending on the rated load and contact selection.
