BZE6-2RN81 Honeywell Limit Switch

Product Summary:
Honeywell BZE6-2RN81 is a rugged electro-mechanical limit switch with a roller lever actuator, electrostatic epoxy-coated zinc housing, and IP66-rated sealing, ideal for precision industrial automation tasks.

Key Features:

• Model: BZE6-2RN81

• Actuator Type: Roller Lever

• Contact Configuration: SPDT (1NO/1NC) snap-action

• Housing: Electrostatic epoxy coated zinc die-cast

• Sealing: NEMA 1, 3, 4 and IP66 with boot seal

• Mechanical Life: Up to 5 million cycles

• Electrical Life: Up to 50,000 cycles at full rated load

• Operating Temp: -32 °C to 71 °C (standard), -40 °C to 71 °C (optional low temp)

• Agency Approvals: UL, CSA, CE, UKCA



Applications:

• Conveyor systems

• Packaging machines

• Material handling units

• Position sensing in automation lines

• Safety interlocks in industrial machinery



Product Benefits:

• Long mechanical and electrical life ensures reduced downtime

• Robust housing ideal for harsh industrial environments

• Precise switching with minimal differential travel (0.05 mm)

• Suitable for low temperature environments up to -40°C

• Globally certified for industrial compliance (UL, CE, UKCA)



Frequently Asked Questions:

Q1: What is the actuator type of BZE6-2RN81?
A1: It uses a roller lever actuator for reliable mechanical engagement in linear or rotary motion systems.

Q2: Is this switch suitable for outdoor or dusty environments?
A2: Yes, with an IP66 sealing and NEMA 4 rating, it's designed for demanding environments including dust and water exposure.

Q3: What kind of applications can it be used in?
A3: It's ideal for conveyors, machinery limit detection, safety interlocks, and position sensing in automation.
