BZE6-2RQ Honeywell Limit Switch

 Product Summary:
The Honeywell BZE6-2RQ is a premium side-mount limit switch with SPDT snap-action contacts and a robust epoxy-coated zinc die-cast housing, ideal for harsh industrial environments.

 Key Features:

• Rugged zinc die-cast housing with electrostatic epoxy coating

• IP66-rated boot-sealed actuator for dust and water resistance

• SPDT snap-action contact configuration (1NO/1NC)

• Operating temperature range: -32 °C to 71 °C

• Mechanical life up to 5 million cycles

• Electrical endurance up to 50K cycles at rated load

• High precision operating point: 38.1 mm ±0.76 mm

• Compact side-mount enclosure design

• UL, CE, CSA, UKCA certified

• Wide actuator compatibility (plunger, roller, lever types)

Applications:

• Packaging and Conveyor Systems

• CNC and Metalworking Machines

• Robotics and Motion Control

• Industrial Safety Interlocking

• Material Handling Equipment

Product Benefits:

• Reliable performance in rugged environments

• Long mechanical and electrical life reduces maintenance

• Compact design fits tight installations

• Flexible mounting and actuator options

• Approved for global industrial standards

FAQs:

Q1: What type of contact configuration does the BZE6-2RQ have?
A1: The BZE6-2RQ comes with SPDT snap-action contacts offering 1NO/1NC configuration for reliable signal switching.

Q2: Is the BZE6-2RQ suitable for outdoor use?
A2: Yes, it features an IP66-rated boot-sealed actuator, making it dust-tight and water-resistant for outdoor or harsh indoor environments.

Q3: How long is the lifespan of the BZE6-2RQ switch?
A3: It offers up to five million mechanical cycles and 50,000 electrical cycles at full rated load, ensuring long-term reliability.
