FLP / Explosion-Proof Universal Head-Mount Temperature Transmitter

A. Product Overview

This Explosion-Proof Temperature Transmitter with LED Display is a field-mounted temperature measurement device designed for hazardous locations where an Ex-proof / explosion-proof enclosure is required. It provides local temperature indication on a high-visibility LED digital display and supports multiple configurable options for sensor type, wiring system, mechanical installation dimensions and transmitter output.

The unit is shown with an explosion-proof grade housing and a waterproof connector/shell construction. It is suitable for applications where customers need a configurable temperature assembly with choices for thread type, probe diameter, probe length, and multiple signal outputs such as 4–20 mA, 0–10 V, 0–5 V or RS-485, depending on the selected configuration.

B. Working Principle

The transmitter measures temperature from the selected sensor and displays the measured value locally on the LED display. Sensor options listed include PT100, PT1000, NTC, thermocouple and DS18B20. Based on the configured transmitter output, the measured temperature is converted into a standard signal for remote monitoring or control systems.

Output options listed include:

• 4–20 mA

• 0–10 V

• 0–5 V

• RS-485

Mechanical ordering/configuration options include thread specification, probe diameter, cold end length (LC), hot end length (LH) and selectable temperature ranges. Wiring system options are listed as 2-wire, 3-wire and 4-wire, enabling matching to the selected sensor type and installation requirement.

C.Key Applications

• Temperature measurement in hazardous areas requiring an explosion-proof enclosure

• Field temperature monitoring where a local LED display is required for quick verification

• Skids and process equipment requiring customizable sensor type, wiring and mechanical dimensions

• Installations needing selectable output signals such as 4–20 mA, voltage output or RS-485

D. Suitable Buyers

• OEMs building skid packages and hazardous-area equipment requiring explosion-proof temperature measurement with local indication

• EPC contractors specifying Ex-proof field instruments with configurable outputs and mechanical options

• Maintenance and utilities teams replacing explosion-proof temperature instruments where field display is required

• Plant engineering and procurement teams standardizing installation formats (threads, lengths, diameters) for retrofit and expansion projects

FAQ SECTION

1. What sensors are supported for this explosion-proof temperature transmitter?
The brochure lists PT100, PT1000, NTC, thermocouple and DS18B20 as supported sensor options.

2. Does the product include a local display?
Yes. It includes an LED digital high-definition display for local temperature indication.

3. What output options are available?
The brochure lists 4–20 mA, 0–10 V, 0–5 V and RS-485 as selectable output options, depending on configuration.

4. What wiring system options are listed?
2-wire, 3-wire and 4-wire wiring system options are listed.

5. What thread options are listed for installation?
Threads listed include M8×1.25, M10×1.5 and other options.

6. What probe diameter options are listed?
Probe diameter options listed include 5 mm, 6 mm, 10 mm and other options.

7. What length options are listed for cold end and hot end?
Cold end length (LC) options include 30 mm, 50 mm, specify, or 0 (no cold end). Hot end length (LH) options include 30 mm, 50 mm and other.

8. What accuracy classes are listed?
Accuracy classes listed are 1/3B (±0.1°C), A (±0.15°C), B (±0.3°C) and C (±0.6°C).

9. What temperature range options are shown?
The brochure shows options such as 100°C, 200°C and other selectable ranges.

10. What construction features are highlighted?
The brochure highlights a waterproof connector, waterproof shell, cold end protection zone and stainless steel thread.
