Honeywell 914CE1-6G Compact Enclosed Limit Switch

Product Summary:

The Honeywell 914CE1-6G is a compact, enclosed limit switch designed for long-life performance in harsh industrial applications. Featuring SPDT snap-action contacts (1NO/1NC), it offers robust environmental sealing up to IP68 and an operating life of up to 10 million mechanical actuations. Suitable for machinery control, safety interlocks, and automation systems.

Key Features:

• SPDT snap action contacts (1NO/1NC)

• Sealing: IP66, IP67, IP68; NEMA 1, 2, 3, 3R, 4, 6, 6P, 12, 13

• Wide operating temperature: 0 °C to 105 °C

• Mechanical life: Up to 10 million operations

• Thermal current: 1 A

• Insulation voltage (Ui): 250 V

• Impulse withstand voltage (Uimp): 1.5 kV

• SCPD: Quick blow fuse compatible

• Pollution Degree: 3

• High shock (50g) and vibration (10g) resistance

• Max. actuation frequency: 200 Hz (AC), 20 Hz (DC)

• Global approvals: UL, CSA, CE



Applications:

• OEM machinery and automation panels

• Material handling and conveyor systems

• Industrial safety interlocks

• Food, pharma, and packaging machines

• Process control & positioning detection



Product Benefits:

• Long mechanical life ensures low maintenance

• Reliable switching performance in harsh conditions

• Compact and versatile for OEM and retrofit use

• Multiple sealing levels suitable for dust, water, and washdown areas

• Certified for global use (UL, CE, CSA)



✅ FAQs

Q1: What is the expected lifespan of the 914CE1-6G switch?
A1: It offers up to 10 million mechanical operations for long-term reliability.

Q2: Can it be used in high-moisture environments?
A2: Yes, the switch supports IP66, IP67, and IP68 sealing suitable for washdowns and outdoor use.

Q3: What type of contacts does this limit switch use?
A3: It uses SPDT snap-action contacts with one normally open (NO) and one normally closed (NC) configuration.
