Honeywell 914CE16-6AN14 Compact Enclosed Limit Switch

Product Summary:
The Honeywell 914CE16-6AN14 is a compact, enclosed front rotary limit switch with a 6-foot cable, designed for harsh industrial applications. It features SPDT snap action contacts (1NO/1NC, Form C), excellent sealing (IP66–IP68), and an extended mechanical life of up to 10 million cycles. Ideal for motion detection, safety interlocks, and rotary applications across automated systems.

Key Features (in points):

• Actuator Type: Front rotary for angular motion detection

• Contact Configuration: SPDT snap action (1NO/1NC), Form C

• Cable Length: 6 feet for extended installation flexibility

• Sealing: IP66, IP67, IP68-rated

• NEMA Rated: 1, 2, 3, 3R, 4, 6, 6P, 12 (boot seal), 13

• Thermal Current: 1 A

• Rated Insulation Voltage (Ui): 250 V

• Rated Impulse Withstand Voltage (Uimp): 1.5 kV

• Mechanical Life: 10 million actuations

• Min./Max Actuation Speed: 0.003 m/s to 0.1 m/s

• Max Actuation Frequency: AC – 200 Hz, DC – 20 Hz

• Shock Resistance: 50 g (IEC 60068-2-27)

• Vibration Resistance: 10 g (IEC 60068-2-6)

• Approvals: cURus, CE, UKCA



Applications (in points):

• Rotary motion detection in industrial machinery

• Conveyor systems and robotic arms

• Door position sensing and mechanical stops

• OEM machinery in harsh environments

• Safety interlocks in process automation



Product Benefits (in points):

• Long mechanical life reduces maintenance frequency

• Rugged sealing ensures reliability in dust, water, and washdown environments

• Front rotary design ideal for levered/rotating applications

• Extended 6-foot cable allows easier integration in large setups

• Certified to global standards: CE, cURus, UKCA



✅ FAQs

Q1: What is the difference between front and side rotary limit switches?
A1: Front rotary models like the 914CE16-6AN14 are optimized for forward-facing mechanical movements or lever-based rotary actuation.

Q2: Is this switch weatherproof and suitable for outdoor use?
A2: Yes, it features IP66, IP67, and IP68 sealing with NEMA enclosure ratings for extreme conditions.

Q3: How long is the cable provided with this switch?
A3: It includes a factory-sealed 6-foot cable for extended installation needs.
