Honeywell 914CE16-N79 Compact Limit Switch with M12 Connector

Product Summary:

The Honeywell 914CE16-N79 is a high-performance compact limit switch featuring SPDT snap action contacts (1NO/1NC) and a M12 male connector for flexible termination. Engineered for harsh industrial conditions, it offers IP66/IP67/IP68 sealing, extended operating temperature range, and a mechanical life of up to 10 million cycles. Ideal for automation, robotics, and OEM applications.

Key Features (in points):

• SPDT snap action contacts (1NO/1NC), Form C

• SJTO 4 x 0.75 mm² (18 AWG) cable termination

• Connector Options:

  • DC: M12, 4-pin male

  • AC: 1/2" x 20 thread, 4-pin male

• Sealing: IP66, IP67, IP68-rated

• NEMA enclosure types: 1, 2, 3, 3R, 4, 6, 6P, 12, 13

• Wide temperature range:

  • Standard: 0 °C to 105 °C

  • Optional: -40 °C to 105 °C

• Mechanical life: Up to 10 million cycles

• Thermal current: 1 A

• Insulation voltage (Ui): 250 V

• Impulse withstand voltage (Uimp): 1.5 kV

• SCPD compatible (quick-blow fuse)



Applications (in points):

• Robotic arms and automation systems

• OEM machine position control

• Packaging and assembly lines

• Harsh and washdown industrial environments

• Mobile equipment and conveyor systems



Product Benefits (in points):

• Long operating life reduces downtime and replacement

• Quick and secure M12 connector for easy installation

• High sealing for reliable use in water/dust-prone areas

• SPDT contacts provide flexible control logic integration

• NEMA and CE/UL certifications ensure global compliance



✅ FAQs

Q1: What connector type is used in the 914CE16-N79 model?
A1: It comes with a 4-pin male M12 connector (DC) and optionally 1/2 in x 20 thread (AC).

Q2: Can this switch operate in sub-zero temperatures?
A2: Yes, the optional version supports operation down to -40 °C.

Q3: What is the mechanical lifespan of this limit switch?
A3: Up to 10 million cycles (5 million for wobble lever variants).
