Honeywell 914CE18-6A Compact Side Rotary Limit Switch

Product Summary:


The Honeywell 914CE18-6A is a compact enclosed limit switch with a side rotary actuator, designed for reliable performance in harsh industrial conditions. It features SPDT snap action contacts (1NO/1NC), robust sealing up to IP68, and versatile connection options including SJTO cable termination and M12/1/2" connectors. With a durable construction and global approvals (CE, UKCA, cURus), it’s ideal for OEMs, automation panels, and rotary position sensing.

Key Features (in points):

• Actuator: Side rotary for angular motion detection

• Contact Type: SPDT snap action (1NO/1NC), Form C

• Termination: SJTO 4 x 0.75 mm² (18 AWG) cable

• Connector Options:

  • DC: M12 male 4-pin (Q, Q2)

  • AC: 1/2” x 20 male 4-pin (Q1)

• Sealing: IP66, IP67, IP68-rated

• NEMA enclosure types: 1, 2, 3, 3R, 4, 6, 6P, 12, 13

• Thermal Current: 1 A

• Rated Insulation Voltage (Ui): 250 V

• Impulse Withstand Voltage (Uimp): 1.5 kV

• Pollution Degree: 3

• Actuation speed: 0.003 to 0.1 m/s

• Actuation frequency: AC – 200 Hz, DC – 20 Hz

• Shock resistance: 50 g (IEC 60068-2-27)

• Vibration resistance: 10 g (IEC 60068-2-6)

• Option: Side cable entry



Applications (in points):

• Conveyor systems and rotary motion detection

• OEM machinery and robotic arms

• Packaging and bottling lines

• Automotive assembly systems

• Harsh environment panel integration



Product Benefits (in points):

• Side rotary actuator ensures precise angular sensing

• Multiple connector options for ease of installation

• IP68 sealing enables use in dust, washdown, or outdoor zones

• SPDT contacts provide flexible dual-function outputs

• Meets international certifications for export-ready deployment



✅ FAQs

Q1: What actuator type does the 914CE18-6A use?
A1: It uses a side rotary actuator, ideal for detecting rotary or levered motion in machinery.

Q2: Are connector versions available for this model?
A2: Yes, it supports M12 (DC) and 1/2” (AC) 4-pin male connectors along with standard cable termination.

Q3: Is this switch suited for wet or dusty environments?
A3: Yes, the unit is sealed up to IP68 and conforms to NEMA 6/6P ratings for extreme industrial conditions.
