Honeywell 914CE2-3AL1 Limit Switch – Top Pin Plunger, 3ft Cable

Product Summary:
The Honeywell 914CE2-3AL1 is a compact, sealed limit switch equipped with a top pin plunger (with boot seal) and a 3-feet cable. With an SPDT snap action contact and IP68 rating, it’s designed to endure harsh industrial conditions, especially low-temperature environments down to -40°C.

Key Features:

• Actuator: Top pin plunger with boot seal

• Cable Length: 3 feet (side entry cable)

• Switching: SPDT, snap action (1NO + 1NC), Form C

• Enclosure Rating: IP66, IP67, IP68; NEMA 1 to 13

• Low temperature operation down to -40°C

• Ui: 250 V | Uimp: 1.5 kV | Ith: 1 A

• Vibration: 10 g | Shock: 50 g (IEC standards)

• Max. actuation frequency: AC – 200 Hz, DC – 20 Hz

• Pollution Degree: 3

• SCPD: Quick blow fuse recommended



Applications:

• Cold storage automation and freezers

• Pharmaceutical and vaccine storage systems

• Harsh outdoor industrial equipment

• Heavy-duty conveyor systems

• OEM machine safety interlocks



Product Benefits:

• Reliable performance in extreme low temperatures

• Long service life reduces downtime

• Side cable entry simplifies cable routing in tight spaces

• Global certifications ensure wide acceptance

• Suitable for rugged and waterproof installations



FAQs:

Q1. Can this switch operate in sub-zero environments?
A1. Yes, it is rated for operation down to -40°C and is suitable for low-temp areas.

Q2. Is the cable flexible for moving applications?
A2. No, the cable is not intended for flexing – ideal for fixed installations.

Q3. What type of contact configuration does it have?
A3. It uses SPDT snap action contacts with 1NO + 1NC arrangement (Form C).
