Honeywell 91MCE1-P2 Limit Switch – Compact, High-Speed, Pre-Wired

Product Summary:
The Honeywell 91MCE1-P2 is a compact limit switch designed for rapid and precise operations in demanding environments. It offers high electrical and mechanical life, fast switching speed, and rugged performance in harsh conditions.

Key Features (Bullet Points):

• Operating speed: 0.05 mm to 1 m/s

• Insulation resistance >100 MΩ at 500 VDC

• Rated voltage: 300 VAC (per EN60947-5-1)

• Thermal current: 10A (pre-leaded), 3A (connector version)

• Electrical rating: AC15 A300, DC13 Q300

• Mechanical life: 5 million operations

• Electrical life: 500,000 operations

• Operating temperature: -25°C to +85°C

• Humidity resistance: < 95% RH

• Compact and sealed design for industrial use



Applications (Bullet Points):

• Machine tools and robotics

• Assembly lines and conveyors

• Packaging and material handling

• Food processing and washdown zones

• Compact automation systems



Product Benefits (Bullet Points):

• Long mechanical and electrical lifespan for reliable performance

• High-speed actuation suitable for rapid switching applications

• Wide operating temperature range for versatile environments

• Compact build fits into tight or modular machine designs

• Pre-wired for easy installation in control panels or field use



FAQs:

Q1: Can this switch be used in high-speed operations?
Yes, it supports an actuation speed range from 0.05 mm/s to 1 m/s.

Q2: Is it suitable for outdoor or humid environments?
Yes, it supports humidity up to 95% RH and temperatures from -25°C to +85°C.

Q3: How many operations can it handle before replacement?
The mechanical life is rated at 5 million cycles, and the electrical life is 500,000 cycles.
