Honeywell 91MCE28-P5 Limit Switch | Industrial Control
High-performance Honeywell 91MCE28-P5 limit switch for precision position sensing in industrial automation systems.
Customize
Share :
Product Summary:
The Honeywell 91MCE28-P5 Limit Switch is a robust, high-precision micro switch designed for reliable mechanical and electrical operation. Engineered to handle demanding automation environments, it offers consistent performance with long life expectancy and a compact form factor.
Key Features:
Operating speed: 0.05 mm to 1 m/sec
High insulation resistance: >100 MΩ @ 500 VDC
Rated voltage: 300 VAC (EN60947-5-1 compliant)
Rated thermal current: 10A (pre-leaded), 3A (connector versions)
Electrical rating: AC 15 A300; DC 13 Q300
Mechanical life: 5 million operations
Electrical life: 500,000 operations
Wide operating temperature: -25°C to +85°C
High humidity resistance: <95% RH
Compact size, durable construction
Operating speed: 0.05 mm to 1 m/sec
High insulation resistance: >100 MΩ @ 500 VDC
Rated voltage: 300 VAC (EN60947-5-1 compliant)
Rated thermal current: 10A (pre-leaded), 3A (connector versions)
Electrical rating: AC 15 A300; DC 13 Q300
Mechanical life: 5 million operations
Electrical life: 500,000 operations
Wide operating temperature: -25°C to +85°C
High humidity resistance: <95% RH
Compact size, durable construction
Applications:
Industrial automation systems
CNC machines and robotic assemblies
Material handling and conveyor systems
Packaging and bottling machinery
Process control and plant monitoring
Industrial automation systems
CNC machines and robotic assemblies
Material handling and conveyor systems
Packaging and bottling machinery
Process control and plant monitoring
Product Benefits:
Long mechanical and electrical life ensures reduced maintenance
Versatile mounting in compact spaces
Wide temperature and humidity tolerance
High current and voltage handling
Trusted Honeywell build quality for critical operations
Long mechanical and electrical life ensures reduced maintenance
Versatile mounting in compact spaces
Wide temperature and humidity tolerance
High current and voltage handling
Trusted Honeywell build quality for critical operations
FAQs:
Q1: What is the maximum operating speed of this switch?
A1: The switch operates reliably from 0.05 mm/sec up to 1 meter/sec.
Q2: Can this limit switch be used in high-humidity environments?
A2: Yes, it supports humidity levels of up to 95% RH.
Q3: What type of industrial machines is this suitable for?
A3: It is ideal for conveyors, robotic arms, CNCs, and general automation systems.
Q1: What is the maximum operating speed of this switch?
A1: The switch operates reliably from 0.05 mm/sec up to 1 meter/sec.
Q2: Can this limit switch be used in high-humidity environments?
A2: Yes, it supports humidity levels of up to 95% RH.
Q3: What type of industrial machines is this suitable for?
A3: It is ideal for conveyors, robotic arms, CNCs, and general automation systems.
