Honeywell 91MCE30-S1 Limit Switch

Product Summary:
The Honeywell 91MCE30-S1 is a premium-quality limit switch designed for industrial automation environments requiring high reliability, compactness, and long mechanical life. With a snap-action mechanism and robust housing, it's ideal for high-speed and repetitive mechanical motion detection.

Key Features:

• Model: 91MCE30-S1 (Pre-leaded version)

• Snap-action mechanism for reliable switching

• Rated voltage: 300 VAC

• Thermal current: 10A (pre-leaded)

• Electrical Rating: AC15 300V | DC13 Q300

• Operating speed: 0.05 mm to 1 m/s

• Insulation resistance: >100 MΩ @ 500 VDC

• Operating Temp: -25°C to +85°C

• Humidity Tolerance: < 95% RH

• Mechanical Life: 5 million operations

• Electrical Life: 500,000 operations



Applications:

• Conveyor belt limit detection

• Machine positioning systems

• Packaging line end stops

• Robotic arm movement limits

• Automated safety interlocks



Product Benefits:

• ⚙️ Long mechanical life ensures reduced maintenance

• ✅ Accurate detection with fast response time

• 🔧 Compact and rugged for tight industrial spaces

• 🔌 Pre-leaded design simplifies installation

• 🌡️ Operates reliably in harsh environments



FAQs:

Q1: What is the maximum voltage supported by this limit switch?
A1: The Honeywell 91MCE30-S1 supports up to 300 VAC.

Q2: Can this limit switch be used in high-speed applications?
A2: Yes, it supports an operating speed of 0.05 mm to 1 m/s, ideal for fast-moving systems.

Q3: Is the switch suitable for outdoor or humid environments?
A3: Yes, it works in temperatures from -25°C to 85°C and up to 95% relative humidity.
