Honeywell 91MCE1-S1 Compact Limit Switch
Compact and reliable Honeywell 91MCE1-S1 limit switch designed for high-speed industrial operations with robust mechanical life.
Customize
Share :
✅ Product Summary:
The Honeywell 91MCE1-S1 is a compact, enclosed limit switch engineered for demanding industrial applications. With high mechanical and electrical life expectancy, it ensures reliable performance even under fast actuation and harsh environmental conditions.
✅ Key Features:
Compact and enclosed design for industrial durability
Wide operating speed range: 0.05 mm/s to 1 m/s
High insulation resistance: >100 MΩ @ 500 VDC
Rated voltage: 300 VAC (EN60947-5-1)
Thermal current: 10A (pre-leaded), 3A (connector)
Electrical ratings: AC15 A300, DC13 Q300
Mechanical life: 5 million operations
Electrical life: 500,000 operations
Temperature range: -25°C to +85°C
Humidity: <95% RH (non-condensing)
Compact and enclosed design for industrial durability
Wide operating speed range: 0.05 mm/s to 1 m/s
High insulation resistance: >100 MΩ @ 500 VDC
Rated voltage: 300 VAC (EN60947-5-1)
Thermal current: 10A (pre-leaded), 3A (connector)
Electrical ratings: AC15 A300, DC13 Q300
Mechanical life: 5 million operations
Electrical life: 500,000 operations
Temperature range: -25°C to +85°C
Humidity: <95% RH (non-condensing)
✅ Application:
Industrial automation equipment
Material handling systems
Packaging machines
Assembly and conveyor systems
Electrical panels and safety enclosures
Industrial automation equipment
Material handling systems
Packaging machines
Assembly and conveyor systems
Electrical panels and safety enclosures
✅ Product Benefits:
Long-lasting operation with minimal maintenance
Accurate and consistent switching performance
Compact design ideal for tight installations
Suitable for high-speed actuations
Withstands tough environments with wide temp range
Long-lasting operation with minimal maintenance
Accurate and consistent switching performance
Compact design ideal for tight installations
Suitable for high-speed actuations
Withstands tough environments with wide temp range
FAQs:
Q1: What is the mechanical life expectancy of this limit switch?
A: It supports up to 5 million mechanical operations, making it ideal for high-cycle industrial use.
Q2: Can this switch handle fast actuation speeds?
A: Yes, it supports operating speeds from 0.05 mm/s to 1 m/s.
Q3: Is this limit switch suitable for outdoor environments?
A: Yes, it performs reliably in humidity <95% RH and temperatures from -25°C to +85°C, though outdoor enclosure may be required.
