Multispan PS24 Series SMPS | 24V DC | 1A to 10A | 24W–240W | Plastic Body | DIN Rail Power Supply

Product Summary:

The Multispan PS24 Series is a versatile range of 24V DC Switch Mode Power Supplies (SMPS) built for industrial and OEM applications. These compact DIN-rail-friendly units offer multiple output ratings from 1A to 10A (24W–240W), with plastic-body enclosures for lightweight panel integration. Designed for long-term reliability, they ensure safe operation with built-in protections and quiet, fanless cooling.

Variants in this listing:

• PS24-10A: 24V DC, 10A, 240W (Plastic Body)

• PS24-6.5A-P: 24V DC, 6.5A, 156W (Plastic Body)

• PS24-2.5A: 24V DC, 2.5A, 60W

• PS24-1A: 24V DC, 1A, 24W

(PS24-5A-P and PS24-1.5A can also be added as future variants.)

🔹 Key Features:

• Input Voltage: 100V–270V AC (100–240V AC for select models)

• Output Voltage: 24V DC

• Output Current Range: 1A, 2.5A, 6.5A, 10A

• Power Output: 24W to 240W

• Body Type: Lightweight Plastic Enclosure

• Mounting: DIN Rail / Panel mount

• Protections:

  • Overload (110–120%, hiccup mode)

  • Short Circuit (auto recovery)

  • Over Voltage (latch-off)

  • Over Temperature (auto reset)

• Cooling: Free air convection (no fan)

• Indicator: Power ON LED

• Ripple & Noise: <1% of Vout

• Efficiency: >86% typical


🔹 Applications:

• PLC & Industrial Control Panels

• Robotic Drives & Motors

• IoT Gateways & Communication Devices

• Relay Modules, Solenoids, and Actuators

• Elevators & Access Control Panels

• Special Purpose Machines (SPM)


🔹 Product Benefits:

• Scalable Current Options: Choose from 1A to 10A output based on load

• Plastic Body Construction: Lightweight and corrosion-resistant

• Efficient Design: Low power loss with minimal heat

• DIN Rail Ready: Ideal for compact control panels

• Comprehensive Protection: Reduces maintenance and system damage risk

• Versatile Application Support: Covers light and heavy industrial loads


❓ FAQs:

Q1. What is the difference between PS24-6.5A-P and PS24-6.5A?
The “P” model indicates a Plastic Body, while functionality and output are the same.

Q2. Are these power supplies suitable for continuous 24/7 operation?
Yes, they are designed for industrial-grade continuous-duty performance.

Q3. Do these SMPS include short-circuit protection?
Yes, all variants come with short circuit, overload, over-voltage, and thermal protection.

Q4. Can I use it for powering PLCs or communication modules?
Absolutely, they are built to handle regulated 24V logic loads with stable output.

Q5. Are these SMPS units DIN rail mountable?
Yes, all models support DIN rail mounting for quick installation in control panels.
