🔹 Product Summary

The POT Type RTD Temperature Transmitter (Head Type, Field Mount) is a high-precision and high-stability temperature transmitter designed for ABS housing. It supports PT100 RTD input and provides 4–20mA output with 24-bit Σ-Δ analog front-end for accurate measurement. Built with electrical isolation and anti-surge protection, it ensures reliable operation in industrial environments.

POT Type RTD Temperature Transm…

🔹 Key Features

• Input Sensor: RTD PT-100

• Output Signal: 4–20mA (2-wire loop powered)

• Working Power Supply: 12–35 VDC

• Measurement Accuracy: ±0.3% (RTD)

• 24-bit Σ-Δ high precision analog front end

• Electrical isolation for signal protection

• Anti-surge, anti-lightning & anti-reverse protection

• Excitation Current: 0.2 mA

• Load Capacity: ≤ 500 Ω

• Temperature Coefficient: ≤ 50 ppm/°C F.S

• Operating Temperature: 0 to 60°C

• Storage Temperature: 0 to 80°C

• Housing Material: PA66

• Compact Size: 110 × 75 × 24 mm

• Mounting Screws: M4 × 2

(Technical details referenced from page 2 specifications table)

POT Type RTD Temperature Transm…

🔹 Applications

• HVAC Systems

• Building Automation

• Pharmaceutical Labs & Industry

• Clean Rooms

• Climate Control in Office Buildings

(As listed under Application section in catalogue page 1)

POT Type RTD Temperature Transm…

🔹 Product Benefits

• Ensures stable and accurate temperature transmission

• Reduces electrical interference damage

• Ideal for building management systems (BMS)

• Compact head-mount design for field installation

• Long operational reliability in industrial setups

• Easy RTD PT100 integration


FAQs

Q1: Which sensor input is supported by this transmitter?

A: It supports RTD PT100 temperature sensor input.

POT Type RTD Temperature Transm…

Q2: What is the output signal of this transmitter?

A: It provides a standard 4–20mA two-wire loop-powered output suitable for PLC and BMS systems.

POT Type RTD Temperature Transm…

Q3: Is it suitable for HVAC and clean room applications?

A: Yes, it is specifically recommended for HVAC, clean rooms, building automation, and pharmaceutical industries.
