UNI-T MSO2104X Mixed Signal Oscilloscope | 100MHz | 4+16 Channels

Product Summary:
The UNI-T MSO2104X is a high-performance 4+16 channel mixed signal oscilloscope with 100MHz bandwidth and advanced debug features like protocol decoding, Bode plot, spectrum analysis, and power analysis.

Key Features:

• 100MHz bandwidth, 4 analog + 16 digital channels

• Real-time sampling up to 5GSa/s

• Memory depth up to 100Mpts

• Up to 2,000,000 wfms/s waveform capture

• 9-in-1 instrument: Oscilloscope, Logic Analyzer, Function Generator, Spectrum Analyzer & more

• Built-in 50MHz 2-ch Arbitrary Waveform Generator

• 10.1” HD capacitive multi-touch screen with gesture control

• Protocol decoding: UART, I2C, SPI (others optional)

• 54 measurement parameters with histogram & trend graphs

• Supports SCPI & web-based remote control



Application:

• Embedded system debugging

• Automotive ECU testing

• Power electronics analysis

• Industrial R&D and lab testing

• Communication protocol analysis



Product Benefits:

• Integrated 9-in-1 functionality reduces equipment cost

• Ultra-high waveform capture rate aids in detecting rare glitches

• Intuitive touchscreen improves productivity

• Built-in logic analyzer enables MSO debugging without external add-ons

• Easily exports waveform data for documentation and compliance



FAQs:

Q1: What makes the MSO2104X ideal for embedded system testing?
A1: Its 16 digital + 4 analog channels with protocol decoding make it perfect for microcontroller and bus-level analysis.

Q2: Can I perform power analysis with this model?
A2: Yes, with the free MSO2000X-PWR upgrade, it includes power measurement features for analyzing power converters and supplies.

Q3: Is it compatible with PC or mobile remote access?
A3: Yes, it includes a built-in web server allowing full control via PC or mobile browser using LAN or USB connection.
