UNI-T MSO3034X 350MHz 4CH | 9-in-1 Mixed Signal Oscilloscope

Product Summary:
The UNI-T MSO3034X 350MHz Oscilloscope is a multifunctional test instrument that integrates 9 essential tools—digital oscilloscope, logic analyzer, waveform generator, spectrum analyzer, voltmeter, frequency counter, protocol analyzer, Bode plot, and power analyzer—into one compact device, ideal for R&D, education, and electronics labs.

Key Features:

• 350 MHz analog bandwidth, 4 analog + 16 optional digital channels

• 5 GSa/s real-time sample rate and 500 Mpts memory depth

• 2M wfms/s capture rate in sequence mode

• 10.1” capacitive HD touchscreen with Ultra Phosphor 3.0

• Built-in WebServer, USB 3.0, LAN, HDMI, SCPI support

• Supports logic analyzer, protocol decoding, and power analysis

• Includes 54 types of measurement and advanced triggering



Applications:

• Embedded system debugging and validation

• R&D labs for waveform, signal, and protocol analysis

• Power electronics and automotive electronics testing

• Communication signal troubleshooting

• Educational institutions for multi-tool training setups



Product Benefits:

• Replaces 9 separate instruments—cost-effective and space-saving

• Ultra-fast waveform capture enables in-depth analysis

• Multi-protocol decoding supports complex signal verification

• Touchscreen interface enhances user experience and speed

• Built-in waveform generator adds value for circuit simulation and testing



FAQs

Q1: Can I use the MSO3034X as a spectrum analyzer?
A1: Yes, it supports up to 4Mpts FFT-based spectrum analysis with frequency setting, waterfall view, and marker functions.

Q2: Are logic probes included?
A2: Logic analyzer software is included, but the UT-M15 16ch logic probes are optional and need to be purchased separately.

Q3: What protocols are supported for decoding?
A3: RS232/UART, SPI, I2C come built-in. Optional protocols include CAN, LIN, FlexRay, MIL-STD-1553B, and more.
