UNI-T MSO3034X Digital Oscilloscope, 4 Channel, 350MHz

The MSO3000X series mixed-signal oscilloscope offers impressive features and performance for advanced measurement needs:

• Bandwidth: The MSO3000X comes in two models, with bandwidth options of 350 MHz (MSO3034X) and 500 MHz.
• Analog Channels: Both models are equipped with 4 analog channels.
• Real-time Sample Rate: The oscilloscope supports a real-time sample rate of 5 GSa/s.
• Maximum Memory Depth: With a memory depth of up to 500 Mpts per channel, it allows for high-resolution waveform capture.
• Waveform Capture Rate: It features an exceptional waveform capture rate of 2,000,000 wfms/s, providing fast waveform acquisition.
• Digital Channels: The oscilloscope includes 16 digital channels, enabling mixed-signal analysis.
• Advanced Features: It supports advanced digital triggers with 10 ps accuracy, 12 types of advanced triggers, serial bus triggering and decoding, and various analysis modes including spectrum analysis, power analysis, histograms, waveform recording, enhanced resolution, and pass/fail testing.
• Display: Equipped with a 10.1-inch capacitive touchscreen, it supports multi-gesture controls for common waveform operations.
• Webserver for Remote Control: The oscilloscope features a webserver for easy remote control.
• Optional Waveform Generator: The 50 MHz dual-channel waveform generator is available as an optional add-on.
• Warranty: Warranty is provided as per the brand’s policy.
