UNI-T MSO7104X 2 GHz 4-Ch Mixed Signal Oscilloscope

Product Summary
The UNI-T MSO7104X packs oscilloscope, logic analyzer, spectrum/FFT, AWG, DVM, frequency counter, protocol, jitter/eye and power analysis into a single 15.6" FHD touchscreen platform—perfect for R&D, embedded and high-speed serial work.

Key Features

• 2 GHz analog bandwidth, 4 analog + 16 digital channels

• 10 GSa/s real-time sample rate, 1 Gpts memory depth

• UltraAcq® capture: 800 k wfms/s (2 M wfms/s sequence)

• Built-in dual-channel 60 MHz AWG with 200+ arb waveforms (option)

• 22 advanced triggers + zone trigger; mask & limit testing standard

• 54 automatic measurements with histogram/line-graph views

• 15.6" 1920×1080 multi-touch, Ultra-Phosphor 3.0 256-level display

• USB 3.0, LAN, HDMI, SCPI & web-server remote control



Applications

• High-speed digital and serial bus debug (UART, I²C, SPI, CAN/LIN, etc.)

• RF & power-electronics frequency analysis up to 2 GHz

• Automotive ECU, aerospace & telecom compliance testing

• University labs and training centres needing an all-in-one bench scope

• Production QA where fast mask/limit testing boosts throughput



Product Benefits

• Consolidates nine instruments—frees bench space & budget

• Deep memory + fast waveform rate reveal elusive glitches

• Touchscreen + gesture control speeds setup and analysis

• Upgradeable protocols/AWG protect investment as needs grow

• Web-server & SCPI let you automate tests from any PC or mobile



FAQs
Q1. Can I add logic-analyzer channels later?
A1. Yes—install the MSO7000X-LA license and UT-M15 probe for 16-digital-channel capture.

Q2. Does the scope decode CAN-FD or FlexRay?
A2. CAN-FD, FlexRay, SENT, Audio and more are available as optional protocol licenses, activated via software key.

Q3. Is an internal waveform generator included?
A3. A 60 MHz dual-channel AWG is available; order the “-AWG” option or upgrade later without hardware changes.
