UNI-T UPO1104 Digital Oscilloscope – 100 MHz, 4 Channel

Product Summary:

• The UNI-T UPO1104 digital oscilloscope is a 4-channel, 100 MHz instrument designed with Fast Acquire Phosphor technology and deep memory. It delivers high-speed sampling up to 2 GSa/s and advanced decoding features, perfect for modern electronics and research tasks.

Key Features:

• 100 MHz Bandwidth with 4 channels

• Real-time sampling rate: 2 GSa/s

• Waveform capture rate: 150,000 – 500,000 wfm/s

• Storage depth: 56 Mpts

• Supports RS232/UART, I2C, SPI bus decoding

• 7-digit frequency meter & 36 auto measurements

• 120,000 waveform recording & 1M FFT points

• Interfaces: USB Host, USB Device, LAN

• Built-in DVM and real-time hardware decoding

• 3-Year Warranty (Authorized Distributor – ToolWorld)


Applications:

• Communication and Networking

• Semiconductor and IC design

• Industrial and Consumer Electronics

• Computer Hardware Testing

• Automotive Electronics Diagnostics

• Instrumentation & Field Maintenance

• R&D Labs and Engineering Colleges

Product Benefits:

• High-speed capture enables detailed signal visualization

• 4-channel design enhances multi-point analysis

• Real-time decoding improves troubleshooting efficiency

• Deep memory enables long waveform recording

• Suitable for a wide range of electronic and industrial sectors

FAQs:

Q1. What is the maximum sampling rate of the UNI-T UPO1104?
A1. The oscilloscope supports a real-time sampling rate of up to 2 GSa/s.

Q2. Can this model decode serial communication protocols?
A2. Yes, it supports RS232/UART, I2C, and SPI protocol decoding.

Q3. Is this model suitable for educational institutions?
A3. Absolutely. Its features and affordability make it ideal for engineering labs and technical training.
