UNI-T UTD2052CEX+ Digital Oscilloscope

The UTD2052CEX+ is a dual-channel digital storage oscilloscope (DSO) with advanced features to enhance measurement efficiency and handle complex signal testing scenarios. Key features include:

1. Bandwidth & Sampling Rate:

   • 50 MHz bandwidth.
   • Real-time sample rate of 1 GSa/s.

2. Measurement Capabilities:

   • Offers 34 types of automatic parameter measurements.
   • Supports common mathematical operations.
   • Memory depth of 64 kpts for detailed waveform analysis.
   • Waveform acquisition rate of ≥5000 wfms/s.

3. Display & User Interface:

   • Features a 7-inch HD color TFT LCD screen.
   • Display range of 8 div x 16 div.
   • Incorporates a new Autoset strategy for easy handling of complex test scenarios.

4. Signal Output & Functionality:

   • Multi-frequency square wave output with options of 10 Hz, 100 Hz, 1 kHz, and 10 kHz.
   • Various parameter measurement and waveform recording capabilities.

5. Performance Specifications:

   • Rise time ≤7 ns.
   • Input impedance of 1 MΩ ±2% with a capacitance of 18 ±3 pF.

6. Ease of Use:

   • Multi-language support with 9 language options to cater to global users.
   • Optimized panel operation for improved workflow efficiency.

7. Additional Details:

   • No logic pod or waveform generator included.
   • Not touchscreen-enabled.

8. Warranty:

   • Comes with a 3-year warranty for reliability and peace of mind.
