Uni-T UTL8512B+ DC Electronic Load 500V 30A

Product Summary:
The Uni-T UTL8512B+ is a high-performance DC electronic load designed for precise and flexible testing. With 500V input, 30A capacity, and 400W power handling, it supports fast dynamic response and offers a large display with programmable features. Ideal for R&D labs and electronic testing.

Key Features:

• Voltage Range: Up to 500V

• Current Capacity: Up to 30A

• Total Power: 400W

• Resolution: 0.1mV / 0.01mA

• Max Dynamic Frequency: 50kHz

• Slew Rate: 0.0006A/μS to 3A/μS

• Interface: RS232 Connectivity

• Programmable LIST Test Mode

• Compact ½ 2U size

• 3-Year Warranty



Applications:

• R&D Testing of Power Supplies

• Battery Discharge & Load Testing

• Electronic Component Testing

• Production Line Quality Checks

• Lab-based Performance Evaluation



Product Benefits:

• High precision for accurate results

• Fast transient response up to 50kHz

• Supports automation with LIST mode

• Long operational life and 3-year warranty

• Easy connectivity with RS232 interface

FAQs:

Q1: What type of tests can the UTL8512B+ handle?
A1: It supports constant voltage, current, resistance, and power modes for comprehensive electronic testing.

Q2: Is it suitable for battery testing?
A2: Yes, it's ideal for battery discharge and performance analysis due to its high current capacity and dynamic response.

Q3: Can it be connected to a computer or automated test system?
A3: Yes, it features RS232 communication for easy integration with automation systems.
