Elitech RC-5+ USB Temperature Data Logger with LCD Display
Elitech RC-5+ TE PDF USB Temperature Data Logger (External Sensor, IP67)
Reusable USB temperature data logger with internal and external sensors, IP67 protection, auto-generated PDF reports, and up to 32,000 readings for pharma, cold chain, and food applications.
The Elitech RC-5+ TE is a reusable USB temperature data logger designed for cold chain, pharma, food, and logistics applications requiring accurate monitoring. Equipped with both internal and external sensors, IP67 protection, and auto-generated PDF reports, it provides reliable and easy-to-download temperature data for audits and quality control.
Key Features
Internal and external temperature sensors
Wide measurement range: -40°C to +85°C external, -30°C to +70°C internal
IP67 waterproof enclosure
Auto-generated PDF/XLS/TXT reports
Up to 32,000 readings
5 alarm ranges (configurable)
USB plug-and-play data download
Replaceable CR2032 battery
Logging interval adjustable from 10 sec to 24 hours
Supports Android phones (via OTG) for report reading
EN12830 certified for cold chain
Technical Specifications
(Data extracted from PDF, Page 2)
| Parameter | Specification |
|---|---|
| Model | RC-5+ TE |
| Measuring Parameters | Temperature |
| External Sensor Range | -40°C to +85°C |
| Internal Sensor Range | -22°F to 158°F / -30°C to +70°C |
| Accuracy | ±0.5°C (-20°C to +40°C), ±1°C others |
| Resolution | 0.1°C / °F |
| Data Capacity | 32,000 readings |
| Logging Interval | 10 seconds – 24 hours |
| Report Format | Auto PDF / XLS / TXT |
| Data Interface | USB |
| Enclosure Rating | IP67 |
| Power Supply | Replaceable CR2032 battery |
| Certifications | EN12830, CE, RoHS |
| Dimensions | 80 × 33.5 × 14 mm |
| Weight | 20 g |
Applications
Pharmaceutical cold chain
Vaccine transport & storage
Medical cabinets & refrigerators
Food logistics & frozen storage
Warehouses & cold rooms
Laboratory temperature monitoring
Blood bag & plasma storage
What’s in the Box
Elitech RC-5+ TE PDF Data Logger
External temperature probe
Calibration Certificate
User Manual
FAQ (6 Q&A)
1) How do I download the data?
Simply plug the logger into a PC or Android phone (via OTG). A PDF report is generated automatically.
2) What is the battery life?
The CR2032 replaceable battery lasts up to 1 year depending on the logging interval.
3) Is it waterproof?
Yes, the device has IP67 protection.
4) Can I configure alarms?
Yes, up to 5 alarm thresholds can be configured.
5) Does it support external probe data?
Yes, RC-5+ TE includes an external sensor for deep-freeze & high-accuracy reading.
6) How many readings can it store?
Up to 32,000 temperature records.
